2014 Aluminum Bar
2014 Aluminum Bar is a heat-treatable aluminum alloy from the 2000 series (Al-Cu-Mg system), engineered to deliver exceptional tensile strength, outstanding machinability, and superior fatigue resistance—making it a go-to material for high-stress components where performance and durability are non-negotiable.2014 aluminum bar rod possesses characteristics such as high strength, high toughness, heat resistance, ease of machining, and forgeability.
-
- Unmatched Strength-to-Weight Ratio: T6 temper offers aerospace-grade strength without the weight of steel.
- Exceptional Machinability: T4 temper produces clean chips and extends tool life—reducing machining costs.
- Fatigue Resistant: Withstands cyclic loads (e.g., engine vibrations, suspension movement) better than many alloys.
- Customizable Tempers: Choose T3/T4 for workability or T6/H18 for maximum rigidity.
- Good Surface Finish: Minimizes post-machining polishing or grinding.
- Cost-Effective: Cheaper than 7000-series alloys for non-critical structural applications.
Our 2014 aluminum rod bar meet or exceed international standards, including ASTM-B-209, EN573, EN485, AMS 4121, ISO9001. Our quality management system ensures compliance with these standards and provides reliable, certified materials for your critical applications.
HSTF Aluminum is a high-quality 2014 aluminum rod bar supplier and manufacturer in China. We have large stock, factory direct price, quality assurance, fast delivery.
Specification
| Alloy | 2014,2A14,2014A |
| Equivalent Names | UNS A92014, UNS A92014,EN AW-2014,AlCu4SiMg, 3.1255,AA 2014,Al2014 |
| 2014,2014A Aluminum Bar Temper | T3,T4,T6,T651,T6510,T351,T6511 |
| 2014,2014A Aluminum Bar Types | Square, Round, Hex, Flat, Wire In Black & Bright Finish |
| 2014,2014A Extruded Aluminum Round Bar Diameter | Φ5-200mm |
| 2014,2014A Extruded Aluminum Square Bar Diameter | 5-200mm |
| 2014,2014A Extruded Aluminum Hexagonal Bar Diameter | 5-200mm |
| 2014,2014A Extruded Aluminum Flat Bar Specifications | Thickness:0.15-40mm Width:10-200mm |
| 2014,2014A Aluminum Cast Bar Diameter | Φ124-1350mm |
| 2014,2014A Aluminum Forged Bar Diameter | Φ100-650mm |
| 2014,2014A Aluminum Bar Length | 1-6m, Random, Fix & Cut Length or as per clients’ requirement |
| 2014,2014A Aluminum Bar Surface | Bright, Polish & Black |
|
Packaging |
|
2014 Aluminum Bar Chemical Composition
| Element | Composition(%) | |
| 2014 | 2014A | |
| Si | 0.15-1.2 | 0.15-0.9 |
| Fe | 0.7 | 0.5 |
| Cu | 3.9-5.0 | 3.9-5.0 |
| Mn | 0.40-1.2 | 0.40-1.2 |
| Mg | 0.20-0.8 | 0.20-0.8 |
| Ti | 0.15 | 0.15 |
| Cr | 0.1 | 0.1 |
| Ni | – | 0.1 |
| Zn | 0.25 | 0.25 |
| Zr+Ti | – | 0.2 |
| Each | 0.05 | 0.05 |
| Total | 0.15 | 0.15 |
| Al | Re | Re |
2014 Aluminum Bar Physical Properties
| Physical Property | Value |
| Density | 2.82 g/cm³ |
| Modulus of Elasticity | 71 GPa |
| Electrical Resistivity | 0.045 x10^-6 Ω.m |
| Thermal Conductivity | 138 W/m.K |
| Thermal Expansion | 23 x10^-6 /K |
| Melting Point | 535 ℃ |
2014 2014A Aluminum Bar Type
2014A T651 Extruded Aluminum Rod
Diameter: Φ5-350mm / Length: 1000-6000mm
2014-T651 extruded Aluminium round bars are circular rods crafted from 2014 aluminum alloy through extrusion, offering outstanding mechanical performance and corrosion resistance, widely used in aerospace, automotive manufacturing, industrial machinery, and more.
2014 2014A T351 Extruded Aluminum Square Bar
Diameter: 5-200mm / Length: 1000-6000mm
2014-T351 extruded aluminum square bars are formed by online extrusion of EN AW-2014 aluminum material. They have a square cross-section, moderate strength, excellent corrosion resistance, and good weldability. They are widely used in shipbuilding, construction engineering, and industrial equipment.
2014 T6 Extruded Aluminum Hexagonal Bar
Diameter: 5-200mm / Length: 1000-6000mm
2014-T6 extruded aluminium hexagonal bar, featuring a hexagonal cross-section, offer stable high strength and good corrosion resistance. They are widely used in automotive manufacturing, sports equipment, high-temperature equipment, and various other fields.
2014 2014A Forged Aluminum Round Bar
Diameter: Φ6-254mm / Length: 1000-6000mm
2014A T6511 aerospace aluminum round bars are high-hardness aluminum bars designed specifically for the aerospace industry, certified to meet aerospace standards like AMS 4153 UNS A92014 QQA 200/2 2014.
2014 2014A T6511 Aerospace Aluminum Round Bar
Diameter: Φ100-650mm / Length: 1000-6000mm
2014 Forged aluminum rod is manufactured through methods such as high-pressure impact or extrusion. They possess extremely high strength, high-temperature resistance, and toughness. They are widely used in aircraft engine components, aerospace bearings, and other high-temperature equipment.
2014 2014A Aluminium Cast Round Bar
Diameter: Φ124-1350mm / Length: 1000-6000mm
Manufacturers primarily use 2014 Aluminium cast round bar for later-stage extrusion billets, with diameters reaching up to 1350mm.
2014 aluminium bars are one of our flagship products. If the 2014 series aluminum bars mentioned above do not meet your project needs, we also have other bars in the 2000 series, such as 2024 aluminum bars and 2017 aluminum bars. Please feel free to contact us if needed.
Application
Aerospace
Combines high mechanical strength with good machinability for durable, lightweight aerospace components.
- Wing spar brackets: high strength and fatigue resistance ensure reliable load transfer in critical airframe structures.
- Landing gear axle sleeves: tough, dimensionally stable bars withstand high impact and cyclic loading during takeoff.
- Engine mounting lugs: excellent machinability allows precise, vibration-resistant attachments for propulsion systems.
Automotive (High‑Performance)
Delivers exceptional strength and wear resistance for demanding powertrain and chassis applications.
- Forged connecting rods: high shear strength and toughness support high‑RPM, high‑load performance engines.
- Suspension uprights: consistent properties yield lightweight, rigid components for improved handling and reduced unsprung mass.
- Transmission input shafts: precision form and surface finish ensure smooth torque delivery and long service life under stress.
Industrial Machinery
Defense & Military
Offers a unique balance of toughness, strength, and precision for rugged military hardware.
- Mounting brackets: high impact resistance and rigidity provide rugged, accurately machined supports for firearms and launchers.
- Armored vehicle reinforcement bars: tough yet lightweight bars enhance protection without compromising mobility.
- Military aircraft structural pins: excellent machinability produces high‑integrity fasteners and pins for mission‑critical assemblies.
